MICROPATTERNED 96- AND 384-WELL
Plates for High-Content Cell Assays

20210121_105852

SmartPattern micropatterned multiwell plates are glass-bottom 96- or 384-well plates containing defined cell-adhesive patterns. The patterns control cell adhesion, shape and spatial organization, creating comparable geometrical conditions across wells for quantitative imaging and cell-based assays.

​

The plates are designed for single-cell or multicellular imaging, high-content screening, dose–response studies and automated workflows. Standard or customized pattern geometries can be selected according to the cell type, assay and imaging requirements.

WHY CONTROL CELL GEOMETRY IN MULTIWELL ASSAYS?

On conventional cell culture surfaces, individual cells can differ substantially in spreading area, shape and position. This geometrical variability can complicate image analysis and the interpretation of cellular phenotypes across experimental conditions.



SmartPattern® technology confines cell adhesion to precisely defined micrometer-scale regions surrounded by a non-adhesive surface.



This approach allows researchers to impose controlled cell geometries and spatial arrangements while maintaining the practical advantages of standard multiwell plate workflows.

​

Unlike conventional glass-bottom imaging plates, SmartPattern® plates combine optical access with predefined cell-adhesive geometries.

KEY BENEFITS OF MICROPATTERNED PLATES

Control Cell Shape and Organization

Define cell spreading area, morphology and spatial positioning using adhesive micropatterns.

Different geometries can be selected according to the biological question, from individual cell confinement to the organization of multicellular groups.

Support quantitative and high-content imaging

The glass-bottom format supports high-resolution microscopy and image-based analysis.

Controlled cell positioning and geometry can facilitate image acquisition, segmentation and quantitative comparisons across experimental conditions.

Scale to multi-condition cell-based assays

The 96- and 384-well formats support experimental replicates, compound treatment studies, dose-response experiments and high-content imaging workflows.

SBS-format plates are designed for integration into standard laboratory handling and automated screening workflows, subject to instrument compatibility.

Adapt micropattern geometry to your assay

Choose from standard micropattern shapes or request customized designs to match the required cell morphology, spatial arrangement and experimental objectives.

PRODUCT SPECIFICATIONS

Specification
SmartPattern Multiwell Plates
Primary workflows
Quantitative imaging, high-content screening, dose–response studies and multi-condition assays
Optical properties
Glass imaging surface with low autofluorescence
Automation
Compatible with robotic liquid-handling workflows
Imaging
Compatible with high-resolution optical imaging and commercially available image-analysis software
Cell organization
Suitable for individual cells or organized multicellular groups
ECM coating options
Available pre-coated with selected ECM proteins or without an ECM protein coating for user-defined functionalization. Compatible options include fibronectin and collagen.
Plate standard
SBS-format plates
Pattern geometries
Disks, lines, triangles, squares, rectangles and grids
Pattern design
Standard or customized geometries
Plate formats
96-well and 384-well plates
Culture surface
Glass bottom with defined cell-adhesive micropatterns surrounded by an anti-adhesive surface

STANDARD MICROPATTERNED PLATE LAYOUT

The standard plate layout provides defined micropattern geometries and dimensions across the wells, allowing researchers to compare different cell-confinement conditions within the same plate.

Map showing micropattern geometries and sizes across a SmartPattern 96-well plate

Standard layout of a SmartPattern 96-well micropatterned plate, showing the distribution of pattern geometries and dimensions across the plate.

Cells cultured on fluorescent SmartPattern micropatterns with different shapes and sizes

Representative microscopy images of cells cultured on SmartPattern adhesive micropatterns of different shapes and sizes. Cell images are paired with fluorescence images of the corresponding circular, square, rectangular, linear, Y-shaped, grid and triangular geometries.

HOW TO USE SMARTPATTERN® MULTIWELL PLATE

SmartPattern® micropatterned multiwell plates can be integrated into standard cell culture and imaging workflows.



The six-step procedure illustrated below covers plate preparation, cell seeding, incubation, removal of unattached cells and microscopic observation.

Experimental conditions should be adapted to the cell type, micropattern geometry and selected ECM coating.

​

Pre-coated SmartPattern® plates are ready for cell seeding, while plates supplied without an ECM protein coating require functionalization with a suitable adhesion protein before use.

Six-step SmartPattern micropatterned multiwell plate workflow showing plate equilibration, cleaning, cell seeding, incubation, removal of unattached cells and microscopy observation.

For detailed handling instructions, recommended experimental conditions and cell-specific optimization, consult the SmartPattern® Micropatterned Multiwell Plates User Guide.

CHOOSING BETWEEN 96-WELL AND 384-WELL MICROPATTERNED PLATES

Both formats provide micropatterned culture surfaces for quantitative cell-based experiments.



96-well plates: An option for assay development, cell-based experiments and screening studies requiring a moderate number of experimental conditions.



384-well plates: An option for larger screening campaigns, increased numbers of experimental conditions and automated high-content workflows.



The choice of plate format should account for cell requirements, available sample volume, micropattern layout, imaging objectives and equipment compatibility.



4Dcell can help select the appropriate format and micropattern configuration for a specific assay.

FREQUENTLY ASKED QUESTIONS

EXPLORE THE SMARTPATTERN® MICROPATTERNING PORTFOLIO

4Dcell offers a comprehensive range of static and dynamic micropatterning solutions, from ready-to-use culture substrates to customizable microfabrication tools.

REQUEST SPECIFICATIONS OR A QUOTE

Looking for a micropatterned 96- or 384-well plate for your cell-based assay?

​

The 4Dcell team can help you identify the appropriate plate format, micropattern geometry, ECM coating and customization options.
